CERTECH 24 Port 19" Cat6 UTP Patch Panel, 110 Termination
Stock Code:
PP24C6
PP24C6
CERTECH 24 Port 19" Cat6 UTP Patch Panel, 110 Termination
Product Details
-
Colour:Black
-
Material:Steel Plate, Plastic housing
-
Surface Finish:Powder Coated
-
Warranty:Standard 5-years limited product warranty
-
Product Width:482.6mm
-
Product Depth:94mm
-
Product Height:44mm
Product Overview
CERTECH 24 Port 19" Cat6 UTP Patch Panel
T568A & T568B Wiring
110 Termination
FEATURES:
Category 6 patch panel exceeds TIA/EIA-568-B.2-1 Category 6 & ISO 11801 2nd edition Class E & EN50173-1 standards
Backward compatible to Category 5e, 5 & 3
Supports termination wiring (T568A/B)
Colour Black
SPECIFICATIONS:
Material: 1.6mm steel plate
Colour: black lacquer
Installation: 19-inch frame/cabinet
Jack wiring: 8p 100μ inch gold plated over 100μ inch nickel
Plug insertion life: 750 cycle min
IDC insertion life: 200 cycle min
Conductor: 22-26AWG
APPROVALS:
UL, ETC & 3P Certified
