CERTECH 18RU 800mm Deep Outdoor Freestanding Cabinet w/ Front & Rear Doors. IP45 Rated

Stock Code:
NROD188X8GY-DD-V2
Height:
1119mm
Width:
850mm
Depth:
866mm
Static Loading Capacity:
800kg
Make an Enquiry
NROD188X8GY-DD-V2
CERTECH 18RU 800mm Deep Outdoor Freestanding Cabinet w/ Front & Rear Doors. IP45 Rated

Product Details

  • Product Type:
    Outdoor - IP45 Rated Freestanding
  • Static Loading Capacity:
    800kg
  • Colour:
    Grey
  • Material:
    Cold Rolled Steel
  • Mounting Profile Thickness:
    2.0mm
  • Mounting Angle Thickness:
    1.5mm
  • Surface Finish:
    Zinc Powder Coated
  • Mounting Hole Type:
    Square
  • Door Style:
    2x Vented Steel
  • Inclusions:
    4x Fans, 4x Filter
  • Security:
    Lockable front & rear doors
  • Assembly:
    Fully Welded Construction
  • Warranty:
    Standard 2-years limited product warranty
  • Warranty (Fans):
    Standard 2-years limited product warranty
  • Product Width:
    850mm
  • Product Depth:
    866mm
  • Product Height:
    1119mm

Product Overview

CERTECH IP45 free-standing racks are robust and reliable enclosures designed to house and protect critical electronic equipment in demanding environments. Constructed from high-quality SGCC steel with a durable zinc powder coating, these racks offer superior corrosion resistance and long-lasting performance. Racks are shipped fully assembled for quick deployment.



Key Features:

  • IP45 Protection: The IP45 rating ensures protection against dust and water jets, making these racks suitable for indoor and outdoor installations in various weather conditions.
  • Fans (IP45 Rated Models)
    Smartly designed, fans (with dust filters) are accessible by lifting the pivoting rain hood, allowing the fans to be serviced without having to remove any rack-mounted equipment. Comes with a thermostat for controlled air flow.
  • Robust Construction: The use of SGCC steel provides excellent strength and rigidity, capable of supporting heavy loads and withstanding vibrations.
  • Corrosion Resistance: The zinc powder coating offers superior protection against rust and corrosion, extending the lifespan of the rack even in harsh environments.
  • Doors
    Front & Rear doors have 130 degrees of movement, swinging from left to right, fitted with a water & dust polyurethane door joint strip.
  • Cable Entry
    Cable entry plates and glands located on the base panel of racks, making for easy cable access.
  • Rack Mounting Compatibility
    All racks are compatible with all EIA-310 compliant 19″ equipment.
  • Vertical Mounting Rails
    Vertical mounting rails can be adjusted back and forth to suit various sizes of equipment. Rack units are numbered front and back for easy equipment installation.
  • Ventilation & Dust Filters (IP45 Rated Models)
    The cabinet design allows natural wind cooling through filtered vents on the front door and venting under the lip of the rain hood, which has a 25mm vented lip and is angled at 75mm, allowing for water run-off. The filters are conveniently located on the front door, allowing for easy access & servicing, without having to remove any rack-mounted equipment.

Applications:



  • Telecommunications: Housing base stations, switching equipment, and other telecommunications infrastructure.
  • Industrial Environments: Enclosing control panels, PLCs, and other industrial automation equipment.

Outdoor Installations: Suitable for use in various outdoor environments, such as roadside cabinets and remote monitoring stations.

Warranty:

  • Warranty is subject to use within static loading specifications and operation within normal environmental conditions.
