Cat6 RJ-45 UTP Straight Through Keystone Joiner - 6pc Pack
Stock Code:
JKC6ST-V2-6
JKC6ST-V2-6
Cat6 RJ-45 UTP Straight Through Keystone Joiner - 6pc Pack
Product Details
-
Colour:Black
-
Material:ABS Plastic UL94V-0
-
Warranty:Standard 5-years limited product warranty
-
Product Width:16.5mm
-
Product Depth:28.4mm
-
Product Height:19.2mm
Product Overview
CERTECH Cat6 RJ45 Straight Through Keystone Joiner - 6pc Pack
MATERIAL
1. Plastic housing: ABS+PC, UL94V-0, black colour
2. Contact bracket: PBT_Glass Fibre, UL94V-0
3. RJ45 jack contacts
3-1. Material: Phosphor bronze with nickel plating
3-2. Gold plating: 50 micro-inch gold plating on surface of plug contact area
4. PCB: FR4, UL94V-0
FEATURES & PERFORMANCE
A. Compliant with ANSI/TIA-568.2-D
B. Compliant with IEC60603-7 dimension and reliability requirement
C. Life (mating cycles): Min. 750 cycles
D. Mating and un-mating force: Max. 20N
E. Retention strength: 7.7kg between jack and plug
F. Operating Temperature: -10°C to +60°C
- Eligible certified warranty: CERTECH 25-year System Performance Warranty where all certification conditions are met and products for part of an end-to-end solution.
