CERTECH 18RU 600 (W) x 800 (D) Premier Series Server Rack - DoE Spec

Stock Code:
NSR186X8DOE
Height:
1010mm
Width:
600mm
Depth:
800mm
Static Loading Capacity:
1,000kg
Make an Enquiry
NSR186X8DOE
CERTECH 18RU 600 (W) x 800 (D) Premier Series Server Rack - DoE Spec

Product Details

  • Product Type:
    DOE Approved
  • Static Loading Capacity:
    1,000kg
  • Colour:
    Black
  • Material:
    SPCC Cold Rolled Steel
  • Mounting Profile Thickness:
    2.0mm
  • Mounting Angle Thickness:
    1.5mm
  • Surface Finish:
    Powder Coated
  • Mounting Hole Type:
    Square
  • Door Style:
    Perforated split Front and Rear doors - Honeycomb style
  • Side Panels:
    Single piece, locakable and removable
  • Security:
    Keyed alike doors & side panels
  • Assembly:
    Supplied complete
  • Warranty:
    Standard 3-years limited product warranty
  • Compliance:
    IEC-60297, ANSI/EIA RS-310-D, IEC297-2, DIN41491-1, DIN41494-7, GB/T3047.2-92
  • Product Width:
    600mm
  • Product Depth:
    800mm
  • Product Height:
    1010mm

Product Overview

CERTECH DoE racks are manufactured around universal 19" standards, providing the ability to use our racks with universal 19" equipment from vendors worldwide. All racks are constructed from high quality cold rolled steel & are shipped fully assembled for quick deployment.



Features

  • 180° Small round lock on doors & side panels
  • Perforated split Front and Rear doors - Honeycomb style
  • Perforated doors provide ventilation for servers and networking equipment

Cable Entry

  • Large cable access glands in the roof & base of the rack, provide access for overhead & underneath run cables.

Rack Mounting Compatibility

  • All racks are compatatible with all EIA-310 complaint 19" equpment.

Vertical Mounting Rails

  • Vertical mounting rails can be adjusted back and forth to suit various sizes of equipment. Rack units are numbered front and back for easy equipment installation.

Integrated Earthing

  • Multiple earthing points & wires are fitted throughout the  rack, on the roof, base, side panels & doors.

Standards

  • Complies with IEC-60297, ANSI/EIA RS-310-D, IEC297-2, DIN41491; PART1, DIN41494; PART7, GB/T3047.2-92

Warranty

  • Warranty is subject to use within sstatic loading specifications and operation within normal environmental conditions.
