EDIMAX Industrial Surveillance VLAN 24-Port Gigabit PoE+ Web Smart Switch w/ 4 Gigabit RJ45 & SFP Combo Ports
Stock Code:
IGS-5428PLC
IGS-5428PLC
EDIMAX Industrial Surveillance VLAN 24-Port Gigabit PoE+ Web Smart Switch w/ 4 Gigabit RJ45 & SFP Combo Ports
Product Overview
Industrial Surveillance VLAN 28-Port Gigabit PoE+ Web Smart Switch with 4 Gigabit RJ45/SFP Combo Ports
- 24 Gigabit Ethernet PoE+ ports and 4 Gigabit RJ45/SFP combo ports
- Wide operating temperature range of -20° ~+65° C (-4° ~+149° F) for industrial or extreme environments
- Dual PoE power budget supplies up to 500W in classic mode and 300W in industrial mode (default)
- One-click to create Surveillance VLAN and auto-discover, auto-enrolled devices all at once
- PoE powered devices (PD) live check to enhance the reliability of the network
- Dual-firmware image for robust failover mechanisms
- Guaranteed PoE long distance to 200 meters
- Power back-feed protection to avoid damaging the PoE ports
- IP Surveillance VLAN and Voice VLAN to enhance video and voice quality
- DHCP snooping to protect the integrity of the legitimate DHCP server and its operations
- IEEE 802.3af/at PoE compliant, up to 30W per port (total power budget: 500W or 300W) for powering PoE-enabled devices
- Supports SNMP v1/v2c/v3, Access Control List (ACL), QoS, 802.1Q VLAN, IPv4/IPv6, Port Trunking, Port Mirroring, IGMP v1/v2/v3 Snooping and etc.
- Supports 56Gbps backplane bandwidth, 41.6Mpps forwarding rate, 8K MAC address table and 9KB jumbo frame
Further Network Connection
The long-range mode provides extended power and data delivery distance to 200 meters (656 ft.) at 10Mbps full-duplex operation on a per-port basis.
Stable and Reliable Network
The switch has two firmware stores. The additional backup firmware can be activated while the main firmware goes under restoration, reducing system downtime.
